Performance Characteristics:

1. The printing transmission uses motor transmission, which is sensitive and fast;
2. The lifting is driven by the motor, frequency conversion speed regulation, and the whole machine runs smoothly;
3. The squeegee and the ink return knife have air pressure adjustment device, and the printing thickness is adjustable;
4. Vacuum adsorption fixed prints;
5. The workbench has up and down, left and right, front and back fine-tuning devices, so that the plate is more accurate and convenient;
6. Equipped with a safety device, so that the printing head stops at the upper position, with reliable safety;
7. The electronic control unit is controlled by microcomputer control, and the operation of the whole machine is simpler, more flexible, and easy to maintain.

Scope Of Application

Widely used in film switching, heat transfer printing, and water transfer printing; Soft circuit, single-sided double-sided circuit board, PCB, LED, SMT solder paste printing; Plastic, glass, keyboard, metal, leather, textile printing.
